Full Specifications

EIZO ColorEdge CG2700X-BK

Panel
Model Variations	CG2700X-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	26.9" (68.4 cm)
Native Resolution	3840 × 2160 (16:9)
Pixel Density	164 ppi
Display Colors	1.07 billion (10-bit), 16-bit LUT
Brightness	500 cd/m²
Contrast Ratio	1450:1
Response Time	13 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%, DCI-P3: 98%
Video Signals
Input Terminals	USB Type-C (DP Alt, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3)
Scanning Frequency	USB-C/DP: 25–137 kHz / 23–61 Hz HDMI: 15–135 kHz / 23–61 Hz
USB
Upstream	USB 3.1 Gen 1 Type-C (DP Alt, PD 94W max.), Type-B
Downstream	USB 3.1 Gen 1 Type-A × 2, USB 2.0 Type-A × 2
LAN Adapter	RJ-45 (1000BASE-T)
Power
Requirements	AC 100–240 V, 50/60 Hz
Typical Consumption	34 W
Maximum Consumption	225 W
Power Save Mode	0.5 W or less
Built-in Calibration Sensor	Yes
Features & Functions
Brightness Stabilization	Yes
Digital Uniformity Equalizer	Yes
Preset Modes	User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, AdobeRGB, sRGB, CAL, SYNC_SIGNAL
HDR Gamma	HLG, PQ curve
OSD Languages	English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese
Physical Specifications
Dimensions (with Stand)	638 × 415.9–570.9 × 245 mm
Dimensions (without Stand)	638 × 390 × 86.2 mm
Net Weight	9.7 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Warranty	5 Years Zero bright sub-pixels for 6 months from purchase.
Dimension Drawing	Download PDF ↗

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CG2700S-BK

Panel
Model Variations	CG2700S-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	27.0" (68.5 cm)
Native Resolution	2560 × 1440 (16:9)
Viewable Image Size (H × V)	596.7 × 335.7 mm
Pixel Pitch	0.233 × 0.233 mm
Pixel Density	109 ppi
Display Colors	1.07 billion (10-bit), 16-bit LUT
Viewing Angles (H / V)	178°, 178°
Brightness	400 cd/m²
Contrast Ratio	1600:1
Response Time	19 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%, DCI-P3: 98%
Video Signals
Input Terminals	USB Type-C (DP Alt, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3)
Scanning Frequency	USB-C/DP: 26–89 kHz / 23–61 Hz HDMI: 15–89 kHz / 23–61 Hz
USB
Upstream	USB 3.1 Gen 1 Type-C (DP Alt, PD 92W max.), Type-B
Downstream	USB 3.1 Gen 1 Type-A × 2, USB 2.0 Type-A × 2
LAN Adapter	RJ-45 (1000BASE-T)
Power
Requirements	AC 100–240 V, 50/60 Hz
Typical Consumption	17 W
Maximum Consumption	187 W
Power Save Mode	0.5 W or less
Built-in Calibration Sensor	Yes
Features & Functions
Brightness Stabilization	Yes
Digital Uniformity Equalizer	Yes
Preset Modes	User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, AdobeRGB, sRGB, CAL, SYNC_SIGNAL
HDR Gamma	HLG, PQ curve
OSD Languages	English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese
Dedicated Software
Quick Color Match	Supported
ColorNavigator 7	Supported
Physical Specifications
Dimensions (with Stand)	638 × 415.9–570.9 × 245 mm
Dimensions (without Stand)	638 × 390 × 86.2 mm
Dimensions (with Hood)	657.4 × 425.6–580.6 × 353.5 mm
Net Weight	9.4 kg
Net Weight (Without Stand)	6.4 kg
Net Weight (With Hood)	10.1 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics, TUV/Color Accuracy (Quick Stability), FograCert Softproofing System (class A)
Supplied Accessories
Signal Cables	USB Type-C (2 m), HDMI (2 m)
Others	AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Adjustment certificate, Monitor hood, Warranty card
Warranty	5 Years Zero bright sub-pixels for 6 months from purchase (Sept 1, 2015 or later).

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CG2400SV-BK

Panel
Model Variations	CG2400SV-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	24.1" (61.1 cm)
Native Resolution	1920 × 1200 (16:10)
Viewable Image Size (H × V)	518.4 × 324.0 mm
Pixel Pitch (H × V)	0.270 × 0.270 mm
Pixel Density	94 ppi
Display Colors	1.07 billion (10-bit), 16-bit LUT
Viewing Angles (H / V)	178°, 178°
Brightness	400 cd/m²
Contrast Ratio	1800:1
Response Time	11 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%, DCI-P3: 98%
Video Signals
Input Terminals	DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3), BNC (3G/HD-SDI)
Output Terminals	BNC (3G/HD-SDI, through-out active)
Scanning Frequency	DisplayPort: 26–76 kHz / 23–61 Hz HDMI: 15–76 kHz / 23–61 Hz
USB
Upstream	USB 5Gbps: Type-B × 2
Downstream	USB 5Gbps: Type-A × 2, USB 2.0 Type-A × 2
Audio
Input Terminals	DisplayPort, HDMI, BNC (SDI)
Output Terminals	Headphones (Stereo mini jack)
Power
Power Input	AC 100–240 V, 50/60 Hz
Typical Consumption	18 W
Maximum Consumption	64 W
Power Save Mode	0.5 W or less
Built-in Calibration Sensor	Yes
Features & Functions
Brightness Stabilization	Yes
Digital Uniformity Equalizer	Yes
Preset Modes	User, BT.709, BT.2020, DCI-P3, PQ_DCI-P3, PQ_BT.2100, HLG_BT.2100, sRGB, CAL, SYNC_SIGNAL
HDR Gamma	HLG, PQ curve
OSD Languages	English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese
Software
ColorNavigator 7	Supported
Physical Specifications
Dimensions (with Stand)	554.4 × 408.1–563.1 × 245 mm
Dimensions (without Stand)	554.4 × 374.1 × 70.2 mm
Dimensions (with Hood)	564.4 × 413.1–568.1 × 330 mm
Net Weight	8.5 kg
Net Weight (Without Stand)	5.5 kg
Net Weight (With Hood)	9.0 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, UKCA, TUV/GS, cTUVus, FCC-A, CAN ICES (A), VCCI-A, RCM, RoHS, WEEE, TUV/Ergonomics
Supplied Accessories
Signal Cables	DisplayPort (2 m), HDMI (2 m)
Others	AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Factory Report, Monitor hood, Warranty card
Warranty	5 Years Zero bright sub-pixels for 6 months from purchase (Sept 1, 2015 or later).

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CG2400S-BK

Panel
Model Variations	CG2400S-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	24.1" (61.1 cm)
Native Resolution	1920 × 1200 (16:10)
Viewable Image Size (H × V)	518.4 × 324.0 mm
Pixel Pitch (H × V)	0.270 × 0.270 mm
Pixel Density	94 ppi
Display Colors	1.07 billion (10-bit), 16-bit LUT
Viewing Angles (H / V)	178°, 178°
Brightness	400 cd/m²
Contrast Ratio	1800:1
Response Time	11 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%, DCI-P3: 98%
Video Signals
Input Terminals	USB Type-C (DP Alt, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3)
Scanning Frequency	USB-C/DP: 26–76 kHz / 23–61 Hz HDMI: 15–76 kHz / 23–61 Hz
USB
Upstream	USB 5Gbps Type-C (DP Alt, PD 70W max.), USB 5Gbps Type-B
Downstream	USB 5Gbps Type-A × 2, USB 2.0 Type-A × 2
Power
Power Input	AC 100–240 V, 50/60 Hz
Typical Consumption	17 W
Maximum Consumption	150 W
Power Save Mode	0.5 W or less
Built-in Calibration Sensor	Yes
Features & Functions
Brightness Stabilization	Yes
Digital Uniformity Equalizer	Yes
Preset Modes	User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, Adobe RGB, sRGB, CAL, SYNC_SIGNAL
HDR Gamma	HLG, PQ curve
OSD Languages	English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese
Software
Quick Color Match	Supported
ColorNavigator 7	Supported
Physical Specifications
Dimensions (with Stand)	554.4 × 408.1–563.1 × 245 mm
Dimensions (without Stand)	554.4 × 374.1 × 70.2 mm
Dimensions (with Hood)	564.4 × 413.1–568.1 × 330 mm
Net Weight	8.5 kg
Net Weight (Without Stand)	5.5 kg
Net Weight (With Hood)	9.0 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, RoHS, WEEE, TUV/Ergonomics
Supplied Accessories
Signal Cables	USB Type-C (2 m), HDMI (2 m)
Others	AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Factory Report, ScreenCleaner, Monitor hood, Warranty card
Warranty	5 Years Zero bright sub-pixels for 6 months from purchase (Sept 1, 2015 or later).

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CS2740-BK

Panel
Model Variations	CS2740-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	26.9" (68.4 cm)
Native Resolution	3840 × 2160 (16:9)
Viewable Image Size (H × V)	596.2 × 335.3 mm
Pixel Pitch (H × V)	0.155 × 0.155 mm
Pixel Density	164 ppi
Display Colors	1.07 billion from a palette of 278 trillion
Viewing Angles (H / V)	178°, 178°
Brightness	350 cd/m²
Contrast Ratio	1000:1
Response Time	10 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%
Video Signals
Input Terminals	USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 2.2 / 1.4)
Scanning Frequency	USB-C / DP: 25–137 kHz / 23–61 Hz HDMI: 15–135 kHz / 23–61 Hz
USB
Upstream	USB 3.1 Gen 1: Type-C (DP Alt, PD 60W max.), USB 3.1 Gen 1: Type-B
Downstream	USB 3.1 Gen 1: Type-A × 2, USB 2.0: Type-A × 2
Power
Power Input	AC 100–240 V, 50/60 Hz
Typical Consumption	36 W
Maximum Consumption	168 W
Power Save Mode	1.0 W or less
Features & Functions
Digital Uniformity Equalizer	Yes
Preset Modes	User, Adobe RGB, sRGB, Calibration
OSD Languages	English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Others	Color Adjustment, Input Color Format, YUV Color Matrix, Input Range, Noise Reduction, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Key Lock, DUE Priority
Software
Quick Color Match	Supported
ColorNavigator 7	Supported
Physical Specifications
Dimensions (with Stand)	638 × 404.1–559.1 × 265 mm
Dimensions (without Stand)	638 × 378.2 × 75 mm
Net Weight	10.3 kg
Net Weight (Without Stand)	6.7 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics
Supplied Accessories
Signal Cables	USB Type-C (2 m), DisplayPort (2 m)
Others	AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Warranty card, VESA mounting screw × 4
Warranty	5 Years Zero bright sub-pixels for 6 months from purchase (Sept 1, 2015 or later).

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CS2731-BK

Panel
Model Variations	CS2731-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	27" (68.5 cm)
Native Resolution	2560 × 1440 (16:9)
Viewable Image Size (H × V)	596.7 × 335.7 mm
Pixel Pitch (H × V)	0.233 × 0.233 mm
Pixel Density	109 ppi
Display Colors	USB Type-C, DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion DVI: 16.77 million from a palette of 278 trillion
Viewing Angles (H / V)	178°, 178°
Brightness	350 cd/m²
Contrast Ratio	1000:1
Response Time	10 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%
Video Signals
Input Terminals	USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 1.4), DVI-D (HDCP 1.4)
Scanning Frequency	USB Type-C, DisplayPort, DVI: 26–89 kHz / 23–61 Hz HDMI: 15–89 kHz / 23–61 Hz
USB
Upstream	USB 3.1 Gen 1: Type-C (DP Alt, PD 60W max.), USB 3.1 Gen 1: Type-B
Downstream	USB 3.1 Gen 1: Type-A × 2, USB 2.0: Type-A × 2
Power
Power Input	AC 100–240 V, 50/60 Hz
Typical Consumption	34 W
Maximum Consumption	159 W
Power Save Mode	1.0 W or less
Standby Mode	1.0 W or less
Features & Functions
Digital Uniformity Equalizer	Yes
Preset Modes	Color Mode (User, Adobe RGB, sRGB, Calibration)
OSD Languages	English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Others	Color Adjustment, Input Color Format, YUV Color Matrix, Input Range, Noise Reduction, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority
Software
Quick Color Match	Supported
ColorNavigator 7	Supported
Physical Specifications
Dimensions (Landscape, W × H × D)	638 × 404.1–559.1 × 265 mm
Dimensions (Portrait, W × H × D)	378.2 × 649–689 × 265 mm
Dimensions (Without Stand, W × H × D)	638 × 378.2 × 75 mm
Net Weight	10.1 kg
Net Weight (Without Stand)	6.5 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics
Supplied Accessories
Signal Cables	USB Type-C (2 m), HDMI (2 m)
Others	AC power cord, USB cable, Setup guide, Warranty card
Warranty	5 Years Zero bright sub-pixels for 6 months from date of purchase for purchases made on September 1, 2015 or later.

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Full Specifications

EIZO ColorEdge CS2400S-BK

Panel
Model Variations	CS2400S-BK
Type	IPS
Backlight	Wide-Gamut LED
Size	24.1" (61.1 cm)
Native Resolution	1920 × 1200 (16:10)
Viewable Image Size (H × V)	518.4 × 324.0 mm
Pixel Pitch (H × V)	0.270 × 0.270 mm
Pixel Density	94 ppi
Display Colors	1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT)
Viewing Angles (H / V)	178°, 178°
Brightness	410 cd/m²
Contrast Ratio	1350:1
Response Time	19 ms (gray-to-gray)
Color Gamut	Adobe RGB: 99%
Video Signals
Input Terminals	USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3)
Scanning Frequency	USB Type-C, DisplayPort: 26–76 kHz / 23–61 Hz HDMI: 15–76 kHz / 23–61 Hz
USB
Upstream	USB 5Gbps: Type-C (DP Alt, PD 70W max.), USB 5Gbps: Type-B
Downstream	USB 5Gbps: Type-A × 2, USB 2.0: Type-A × 2
Power
Power Input	AC 100–240 V, 50/60 Hz
Typical Consumption	18 W
Maximum Consumption	149 W
Power Save Mode	0.30 W
Built-in Calibration Sensor	—
Features & Functions
Brightness Stabilization	—
Digital Uniformity Equalizer	Yes
Preset Modes	User, Adobe RGB, sRGB, Calibration (CAL)
OSD Languages	English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Others	Color Adjustment, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority
Software
Quick Color Match	Supported
ColorNavigator 7	Supported
Physical Specifications
Dimensions (Landscape, W × H × D)	554.4 × 396–551 × 245 mm
Dimensions (Without Stand, W × H × D)	554.4 × 362 × 64 mm
Net Weight	8.2 kg
Net Weight (Without Stand)	5.2 kg
Height Adjustment	155 mm
Tilt / Swivel / Pivot	35° Up, 5° Down / 344° / 90°
VESA Mount	100 × 100 mm
Environmental Requirements
Operating Temperature	0–35°C
Operating Humidity	20–80% R.H. (non-condensing)
Certifications & Standards	CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, RoHS, WEEE, TUV/Ergonomics
Supplied Accessories
Signal Cables	USB Type-C (2 m), HDMI (2 m)
Others	AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Factory Report, Warranty card
Warranty	5 Years Zero bright sub-pixels for 6 months from date of purchase for purchases made on September 1, 2015 or later.

ℹ️ Please contact EIZO for the latest certifications info. Accessories may vary by country.

Compelling results and increased productivity

Monitor Series

CG Series

CG2700X

CG2700S

CG2400SV

CG2400S

CS Series

CS2740

CS2731

CS2400S

CS2400R
